UFO Power Design System

High-Performance Lithium Battery Solutions

15 years of OEM/ODM experience in developing cutting-edge lithium-ion batteries with superior discharge rates, ultra-low temperature performance, and exceptional safety standards.

HV Lipo UAV Battery
Battery Technology

HV Lipo UAV Battery

Model: 6S 22.8V

Technical Specifications

Voltage: 22.8V
Capacity: 24Ah
Dimensions: mm
Energy Density: 240Wh/kg
Weight:
Operating Temp: °C
Cycle Life:
Charge/Discharge:

Product Description

Product Details:

6S 24000mAh 10C LiPo Battery – Empowering Industrial UAVs with Elite Performance, Safety, and Customization Set new standards in industrial UAV operations with the 6S 24000mAh 10C LiPo battery—meticulously engineered to satisfy the stringent demands of professional drone applications where uptime, mission endurance, and operational safety are paramount.
Key Features and Business Advantages:
  • Massive 24,000mAh Capacity: Delivers industry-leading flight endurance, supporting extended missions and reducing the frequency of battery changes. Ideal for long-range surveying, high-tempo inspections, and complex data acquisition tasks.
  • Reliable 10C Continuous Discharge: Ensures stable and robust power delivery for heavy-payload UAVs, advanced gimbal/camera integrations, and high-consumption industrial peripherals even under challenging load profiles.
  • High-Precision Cell Consistency: Utilizes top-tier, tightly matched lithium polymer cells, resulting in superior balance, minimal voltage drift across cycles, and enhanced longevity—drastically reducing downtime and total cost of ownership.
  • Ruggedized Construction for Industrial Environments: Features heavy-duty casing, advanced vibration resistance, and impact protection—purpose-built to withstand harsh field conditions encountered in industrial, utility, and emergency response operations.
  • Strict Production & Quality Validation: Every battery is subjected to comprehensive electrical, thermal, and performance testing, guaranteeing uniform reliability and compliance with international safety standards.
  • Custom Engineering Solutions: Tailorable connector types, form factors, and voltage profiles are available to ensure optimal compatibility and seamless integration within specialized UAV fleets and mission requirements.


6S 24000mAh 22.8V 10C Lipo Drone Battery Specifications :

●Minimum Capacity: 23000mAh ●Configuration: 6S / 22.8V / 6 cells ●Discharge Rate: 25C ●Max Burst Discharge Rate: 50C ●Net Weight(±20g): 2474g ●Dimensions: 208mm Length x 91mm Width x 62mm Height

Applications :

UFO LiPo drone batteries feature high energy density and high discharge rates, making them ideal for a wide range of commercial and professional UAV applications, including:
  • Agricultural spraying drones
  • Land surveying drones
  • Police and public safety drones
  • eVTOL aircraft
  • Delivery drones
  • Inspection and monitoring drones
  • Aerial photography drones
  • Construction site drones
  • Mining and exploration drones


Customized Solutions are accepted .
